Navy AN/SRA-12 Receiver Multicoupler Filter

Complete manual pdf

sra12-102.JPG (485836 bytes) sra12-103.JPG (325977 bytes) sra12-104.JPG (253447 bytes) sra12-105.JPG (549190 bytes)
